Barway Mini Portable Barcode Scanner For 1D 2D QR Barcode Usb CE A4 CCD Stock Manual Minno Apex 6 Scanner 4 Miles 32 Bit

WP80 2D Barcode Scanner Product features

*It can interpret various one-dimensional codes / two-dimensional codes, directly transmit Chinese two-dimensional codes, and wireless BT is 20 meters wide

512,000 characters can be stored in offline / inventory storage mode

It can be directly paired with mobile phones, tablets and laptops with BT function

How to use the scanner ?

1. Press the button, when the blue light is on, the scanner starts.
2. Plug the receiver to your computer, the blue light is on, the receiver starts to work.
3. Please match the receiver and the scanner within 30 seconds!
4. Open a text, Scan any barcode to see if the barcode can be uploaded.

Two Scan Mode:

Instant upload mode:Scan the bar code, the data will be uploaded to your device in sync
Storage mode: Scan the bar code and store the data inside the built-in storage of scanner, and then upload the data to your device
when you need it.

performance parameter
Image sensor	617nm led aiming light, white LED illumination light
Decoding capability	1D: code128ean-13 / isbnisnncode32ean-8, UPC-A UPC-E,UCC/EAN-128Code39CodabarCode93, Interleaved2of5. Industrial2of5/Stander2of5/IATA2of5 Matrix2of5Code11MSIPlesseyUKGS1DataBar. GS1 DataBarLimitGS1DataBarExpand,Datalogic2of5. 2D: QRcode, datamatrixpdf417, MicroPDF417, aztecode, direct transmission to Chinese
Resolution	640 * 480
Trigger mode	manual scanning / continuous scanning / automatic induction scanning scanning angle: angle 360 ° elevation ± 55 ° deflection ± 55 scanning accuracy: ≥ 5MIL contrast: ≥ 20%
Scanning depth of field	ean1325-150mm (13mil90% PCs); QR 10-120mm (15mil30 bytes); PDF14730-110mm (667mil30 bytes)
Bit error rate	1 / 5 million
Wireless communication mode	paired mobile BT device: BT BLE4.0 wireless transmission distance: 20m (open)
Inventory storage mode	offline storage mode: automatically store data when the scanning gun leaves the connection range, and the storage capacity is 512000 characters
Physical parameters
Size	90mm * 30MM * 21mm (L x W x H)	Material	ABS+PC
Cable standard	0.8m
Environmental parameters
Working temperature	-20 ℃ ~ 50 ℃ storage temperature: - 40 ℃ ~ 70 ℃
Relative humidity	5% ~ 95% (non condensing)
Seismic capacity	it can withstand multiple 12m free falls
Electrical Parameters
Voltage	dc5v5%	Standby current	0ma
Battery charging time	2.5h	Battery working time	4h
Lithium battery	800mA
Charging mode	type charging line, plug-in direct charging
Maximum working current (maximum)	200mA
